0.50 mm

  • Pitch 0.5mm Board to Board Plug, 2.2mm High without Metal Tab
Pitch 0.5mm Board to Board Plug, 2.2mm High without Metal Tab

Pitch 0.5mm Board to Board Plug, 2.2mm High without Metal Tab

Key Specifications:

Material specification:
1. Housing: nylon 9T, plastic (UL94V-0)
2. Contact: phosphor bronze
Electrical performance:
1. Rated voltage (max): 50V AC/DC
2. Rated current (max): 0.5A AC/DC
3. Dielectric strength: 250V AC for 1 minute between adjacent terminal, no breakdown
4. Insulation resistance: 100MΩ min 250V DC for 1 minute between adjacent terminal
5. Contact resistance: 40mΩ max
6. Operating temperature: -25~+85°C
