● DIN41612 Connectors

  • DIN41612 connector,3row*40ways
  • DIN41612 connector,3row*40ways
  • DIN41612 connector,3row*40ways
  • DIN41612 connector,3row*40ways
DIN41612 connector,3row*40waysDIN41612 connector,3row*40waysDIN41612 connector,3row*40waysDIN41612 connector,3row*40ways

DIN41612 connector,3row*40ways

We offers a complete line of standard and custom DIN connectors. Our product offering includes 2, 3, 4 , 5 row products in both male and female versions. Many products are available that are not listed in the pages. If you do not see what you want, please contact us

  • DIN 41612 with different versions:
    • 32way/64way/96way/128way/150way/164way
    • Custom and design new DIN for customer with OEM
  • Material:
    • Insulator: thermal plastic, UL94V-0
    • Contacts: copper alloy
    • Rivet board lock: copper alloy
  • Contact plating:
    • Underplate: 50 to 100μ inches (nickel)
    • Contact area: 1 to 30μ inches (selectivegold)
    • Solder tails area: 100 to 200μ inches tin/(leadfree)
  • Electrical:
    • Operation voltage: 250V AC max
    • Current rating: 1 to 2A max
    • Contact resistance: 20m ohms max
    • Insulation resistance: 3,000M ohms minimum at 500V DC
    • Dielectric withstanding voltage: 1,000V AC/minute
    • Operating temperature: -55 to +125°C

DIN 41612 is a DIN standard for electrical connectors that are widely used in rack-based electrical systems. Standardization of the connectors is a pre-requisite for open systems, where users expect components from different suppliers to operate together.

All products are RoHS Directive-compliant
