● Waterproof D-sub

  • Waterproof D-SUB connector,25PIN,Male, Right angle,DIP
  • Waterproof D-SUB connector,25PIN,Male, Right angle,DIP
  • Waterproof D-SUB connector,25PIN,Male, Right angle,DIP
Waterproof D-SUB connector,25PIN,Male, Right angle,DIPWaterproof D-SUB connector,25PIN,Male, Right angle,DIPWaterproof D-SUB connector,25PIN,Male, Right angle,DIP

Waterproof D-SUB connector,25PIN,Male, Right angle,DIP

  • WDB-25-RA-01-#2288
  • Stable quality
  • Support trial order
  • Competitive price
  • INQUIRY
Many products are available that are not listed in the pages. If you do not see what you want, please contact us.
Waterproof D-SUB
Positions: 9ways, 15ways, 25ways, 37ways,44ways,56ways,72ways.
Electrical Characteristics:
·Contact Current Rating: 5Amperes
·Dielectric Withstanding
·Dielectric Withstanding Voltage: AC 1000Vr.m.s.
·Insulation Resistance: 500 Megohms Minimum ata DC500V
·Contact Resistance: 25 Milliohms Maximum
·Operating Temperature: -55°C-125°C

Materials
·Contact: Brass or phosphor bronze
·Insulator: LCP,ABS,PBT, UL94V-0 Rated
·Shell: Cold Rolle Steel,
·Metal Watertight Frame: PBT, UL94V-0
·0-Ring: Silicone

UL Approved
Compliant with the RoHS Directives
OEM/ODM orders are welcome
