0.80 mm

  • 0.80mm/0.30

0.80mm/0.30" BTB

Key Specifications:

Material specification:
1. Housing: nylon 9T, plastic (UL94V-0)

2. Contact: phosphor bronze

Electrical performance:
1. Rated voltage (max): 50V AC/DC
2. Rated current (max): 0.5A AC/DC
3. Dielectric strength: 250V AC for 1 minute between adjacent terminal, no breakdown
4. Insulation resistance: 100MΩ min 250V DC for 1 minute between adjacent terminal
5. Contact resistance: 40mΩ max
6. Operating temperature: -25~+85°C
