10A Solder Wire D Sub Connector 7pin High Current IP67
D-SUB solder wire waterproof connector

Operating Frequency:Low Frequency
Support Card Number:All in One
Interface Type:D-SUB(VGA)
Certification:ISO 9001, RoHS
Application:PCB, Power, Audio & Video, Automotive
Gender:Male
Product attributes:
Insertion modewelding wire type. 90 °board. 180 °board. Line pressing type. DIDC pressure arrangement type
Type of insertionmale / female head
Insulator material30% UL 94V-0 (green, black, white)
Rated temperature-55 ~ 125
Shelliron, pre-nickel and post-tin (salt spray 24H)
Contact materialbrass, phosphorus copper, (can be customized according to customer's request)
Contact platingall gold 1U "-30U" can be electroplated according to guest's requirement.
Rated current above5A, (large current 10A. 20A / 30A / 40A)
Waterproofing gradeIP67
Signal transient
resistanceless than 10m Ohm
Insulator resistance1000VAC/1 minute at sea level
Coaxial transient
resistance75 or 50 Ohm
High power transient resistance< 2.7 m Ohm
Connector insertion Forcemaximum 15.0kgf
Service lifeabout 500 times
