High current D-Sub connectors designed for power transmission applications. Available in mixed layout and power signal combinations with reliable performance for industrial equipment, automotive and energy systems.
If you don't find what you are looking for, please send inquires by email biz@zyszindustry.com
Thank you!
P/N: D-SUB 3W3 Right angle Through Hole Connector
| Current Rating | Dimension ØA (mm) | Dimension ØB (mm) |
| 40 AMPS | Ø3.75 | Ø4.20 |
| 30 AMPS | Ø3.30 | Ø3.75 |
| 20 AMPS | Ø2.80 | Ø3.28 |
| 10 AMPS | Ø1.70 | Ø2.20 |
| Component | Material Option 1 | Material Option 2 |
| Center Contact | Brass + Gold Plating | Phosphor Bronze + Gold Plating |
| Insulator | PBT + 30% Glass Fiber (G.F) | UL94V-0 Flame Retardant |
| Front Shell | Iron + Nickel Plating | Steel + Passivation |
| Back Shell | Iron + Tin Plating | Steel + Passivation |
Electrical Performance：
| Rated Current (Male) | 10A, 20A, 30A, 40A |
| Rated Current (Female) | 10A, 20A, 30A, 40A |
| Contact Resistance | 10 mΩ |
| Withstanding Voltage | 500V |
| Insulation Resistance | 5000 MΩ |
Mechanical Performance：
| Insertion/Extraction Force | Compliant with IEC 60807-3 standard or customized per customer requirements |
| Mechanical Life | 500 cycles |
| Applicable Wire Gauge | AWG 8/10/12 |
| Mounting Type | Cable-to-cable plug-in connection |
Other Specifications：
| Packaging Type | Blister / Outer carton packaging |
| Environmental Compliance | Meets EU environmental requirements (RoHS compliant) |
| Application Scope | Mechanical equipment, CNC equipment, instruments & meters, etc. |
| Available Configurations | 2w2 / 2v2 / 3w3 / 5w5 / 8w8, etc. |
